Burkert 1062 - Wiring Mechanical Contact Version

29

English
Installationandwiring
 



Donotconnecttheunusedcontactinordertoobviateanydanger•
ofmalfunction.
+
-
NONC
+
-
8 A max.
+
-
1062
Greenlight(open
valvedetection)
Orangelight(volt-
agepresent)
Powersupply
1)
Fusesuitablefor
themax.load
Load
Wiring of the contact when normally open (NO) on a Fig. 7
mechanical contact version, valve open detection
1)
Use a power supply that matches the data shown on the label of the 1062
+
-
NONC
+
-
8 A max.
+
-
1062
Greenlight(open
valvedetection)
Orangelight(volt-
agepresent)
Powersupply
1)
Fusesuitablefor
themax.load
Load
Wiring of the contact when normally closed (NC) on a Fig. 8
mechanical contact version, valve open detection
1)
Use a power supply that matches the data shown on the label of the 1062
