Burkert 1062 - Page 30

30

English
Installationandwiring
1062
+
-
NONC
+
-
8 A max.
+
-
Redlight
(valveclosed
detection)
Orangelight
(voltagepresent)
Powersupply
1)
Fusesuitablefor
themax.load
Load
Wiring of the contact when normally open (NO) on a Fig. 9
mechanical contact version, valve closed detection
1)
Use a power supply that matches the data shown on the label of the 1062
1062
+
-
NONC
+
-
8 A max.
+
-
Redlight(valveclosed
detection)
Orangelight(volt-
agepresent)
Powersupply
1)
Fusesuitablefor
themax.load
Load
Wiring of the contact when normally closed (NC) on a Fig. 10
mechanical contact version, valve closed detection
1)
Use a power supply that matches the data shown on the label of the 1062
