Installationandwiring



Beforestartingwork,switchoffthepowersupplyandsecureit•
topreventrestarting.
Observeallapplicableaccidentprotectionandsafetyregula-•
tionsforelectricalequipment.





Preventtheprojectionoffluidsintothepositionfeedback.•


Preventcontactoftheelectronicswithametalcomponent(a•
screwdriver,forexample).
AssemblethedeviceasshowninChapter
→ 7.,beforewiringit.
CarryouttheelectricalwiringinaccordancewithChapter
→ 8.2.1.
to8.2.6.foryourversionofthe1062.
Oncethedevicehasbeenwired,lockthecablesothatitdoes
→
notimpairthemobilityoftheduplicationrod,byinsertingit
intothenotchesprovidedforthispurposeinthebottomofthe
housing,asshowninFig. 6below:
Fig. 6 Final position of the cable
