Burkert 1062 - Fitting with Stroke Limiter (100-125 mm)

23

English
Assembly






Preventtheprojectionoffluidsintotheactuator.•


Preventtheprojectionoffluidsintothepositionfeedback.•


Preventcontactoftheelectronicswithametalcomponent(a•
screwdriver,forexample).
C
D
Unscrew the cone point set→
screw "C" from the 1062 to
unlock the duplication system
"D" using a hexagonal male
spanner.
Carefullyremovetheduplication
→
system"D"fromthehousingof
the1062.
E
Check that the seals have→
been fitted and that they are
undamaged. Replace them if
necessary.
Putthreadlockintotheinternal
→
thread in the duplication rod
"E".
F
G
Unscrew the small transparent→
cap"F"ontheactuator,preferably
byhandorusingasuitabletoolin
ordernottodamageit
Pumpairintotheactuatorona
→
valve which is normally closed
(function "A") or has a double
effect (function "I") sothat the
actuator rod moves to the top
position.
Unscrew the visual position
→
feedback"G"usingahexagonal
malespanner.
