Burkert 1062 - Page 22

22

English
Assembly
D
Tightentheduplication→
system"D"untilfreecontact
isobtainedwiththetopof
thelimiter,usingaflatNo27
spanner.
Fullytightentheduplication→
rodontheactuatorrodusing
ascrewdriverwithabladeof
suitablesize.
Depressurizetheactuatorofa
→
valvewhichisnormallyclosed
(function"A")orhasadouble
effect(function"I"):thevalve
recoversitsdefaultposition.
C
D
Insertthepositionfeedback→
housingintotheduplication
system"D"settingthecable
glandinthedirectiondesired
andmakingsure,onamecha-
nicalcontactversion,thatyou
donotdamagethecontact
leversontheswitches.
Fastenthehousingandthe
→
duplicationsystembytigh-
teningtheconepointsetscrew
"C"usingahexagonalmale
spanner.
Q
R
Unscrewthecover"Q"onthe
→
positionfeedback.
Unscrewthecablegland"R".
→
Threadthecablethroughthe→
cablegland.
Wireaccordingtothewiring
→
diagramforyourversionofthe
1062:SeeChapter8..
Fastenthecableglandto
→
ensuretightnessoftheproduct.
