Commissioning




Nonconformingcommissioningcouldleadtoinjuriesanddamage
thedeviceanditssurroundings.
Beforecommissioning,makesurethatthestaffinchargehave•
readandfullyunderstoodthecontentsofthemanual.
Inparticular,observethesafetyrecommendationsandintended•
use.
Thedevice/installationmustonlybecommissionedbysuitably•
trainedstaff.
Protectthedeviceagainstelectromagneticinterferenceand•
ultravioletrays.




Activatethevalvetocheckthecorrectdetectionoftheopenand/or
closedposition.
Ifdetectionisincorrect,repositioneachcamoppositeitsswitch
accordingtothepositionofthevalveasshowninthephotosinFig.
17.
Targetofthevalve
openswitch
Activatethevalve
→
so that it opens
completely.
The top cam
→
shouldbelocated
opposite the
targetofthevalve
openswitch.
Targetofthevalve
closedswitch
Activatethevalve→
so that it closes
completely.
Thebottom cam
→
shouldbelocated
oppositethetarget
ofthevalveclosed
switch.
Fig. 17 Correct position of the cams in relation to the switches
