Description


Theelectricalpositionfeedback,combinedwithapneumaticvalve,
isintendedtosignaltheposition-openorclosed-ofthisvalve.
Thepositionofthevalveisgiven:
bylight(s)andbyelectricalsignalonthemechanicalcontact•
versions,ontheinductive3-wireswitch(1output)ordouble
inductive4-wireswitch(2outputs)ordoubleinductive2-wire
NAMURswitch(2outputs)
onlybyelectricalsignalonversionswithinductive2-wireswitch(1•
output).


Theelectricalpositionfeedbackiscomposedofahousing,fitted
withacablegland,withatransparentcover.
Thehousingincludes:
aduplicationsystemthatadaptstothepneumaticactuatorrod-
onthevalve,
oneortwoelectronicboards,eachfittedwithamechanical-
contactlimitswitchoraninductiveswitch,with2or3lights
(exceptforthe2-wireinductiveversions)
aterminalblockforelectricalconnection.-

Theduplicationrodfittedwith2camsmoveswhenthevalveopens
orcloses:themovementofacampasttheswitchassociatedwithit
activatesthelatter.
Whentheswitchisactivated,thelight,ifthereisone,comeson(or
goesoffontheNAMURversions)andanelectricalsignalistrans-
mittedremotely.
ThissignalistransmittedinaccordancewiththeNAMURstandard
ononeversionofthe1062ATEX.


1062 PROXIMITY SWITCH
3-WIRE PNP-NO
10-30V DC NO/NC
MAX:200mA ACTUATOR >80
S/N 1199
00560409 W48LP
Made in France
1
2
3
4
5
6
7
8
9
10
11
Label on the 1062 position feedback, standard versionFig. 1
Typeofdevice
1.
Characteristicsofthelimitswitch2.
Electricalpowersupply3.
Currentconsumption4.
