Burkert 1062 - Page 15

15

English
Technicaldata
Versionwithinductive
2-wireswitch(per
switch)
Powersupply•
Powerconsumption•
Allowableload•
Typeofoutput•


10-30VDC•
≤• 2mA
≤• 100mA
contactnormallyopenornormally•
closed
Versionwithinductive
3-wireswitch(per
switch)
Powersupply•
Powerconsumption•
Allowableload•
Typeofoutput•


10-30VDC•
≤• 25mA
≤• 200mA
NPNorPNP,normallyopenornor-•
mallyclosed
Versionwithdouble
inductive4-wireswitch
Powersupply•
Powerconsumption•
Allowableload•
Typeofoutput•

10-30VDC•
≤• 15mA
≤• 150mA,peroutput
PNP,normallyopen•
Versionwithdouble
inductive2-wire
NAMURswitch
Powersupply•
Powerconsumption•
Allowableload•
Typeofoutput•


8VDC•
≤• 1,2mA(activated)and
>2,1mA(notactivated)
notactivated•
acc.toNAMUR•



max



max

24VDC 5A 5A
30VDC 2A 5A
50VDC 0,7A 1A
74VDC 0,25A 0,6A
125VDC 0,03A 0,4A
250VDC 0,02A 0,25A
125VAC 8A 8A
250VAC 8A 8A
Table 1: Allowable loads for a mechanical contact version
