Technical data
6.3. Mechanical data
Table1: Wettedparts
Part Material
Holder of the ow sensor
PVDF or stainless steel
1.4404/316L
Electrodes
Stainless steel
1.4404/316L
Clamp (only clamp version)
Stainless steel
1.4404/316L
Earthing ring
(only if ow sensor holder in PVDF)
Stainless steel
1.4404/316L
Holder of the electrodes (only if ow
sensor holder in stainless steel)
PEEK
Seal of the ow sensor
(version with G2" nut)
FKM (FDAapproved)
Table2:
Partsnotincontactwiththeuid
Part Material
Housing, cover, nut
• holder of the ow sensor in
stainless steel
• holder of the ow sensor
in PVDF
• PPA, glass ber reinforced
• PC, glass ber reinforced
Screws of the cover Stainless steel
Cable gland PA
Seal of the cover EPDM
Seal of the cable gland Neoprene
Holder of the
ow sensor
Electrodes
holder
Electrodes
Earthing ring
Fig.3: Partsoftheowsensorholderinstainlesssteel(left)or
inPVDF(right),deviceswithaG2"nut
Clamp
Holder of the ow
sensor
Electrodes holder
Electrodes
Fig.4: Partsoftheowsensorinstainlesssteelwithaclamp
connection
