Adjustment and commissioning
9.2. Description of the electronic board
The device has 2 operating modes: the Read mode and the
Parameterizing mode. The functions of each mode are summa-
rised in the following table.
Operating mode Functions
Read To view:
• the uid velocity measured by the
device;
• the values set for the relay function.
Parameterizing
• To calibrate the device.
• To set the relay parameters.
The 5 switches, the push-button, the green LED, the red LED
and the bargraph are used to set the parameters of the device
(see Fig.25).
