Adjustment and commissioning
1 2 3 4 5 6
4...20 V+ V- PE Pls+Pls-
ON
1 2 3 4 5 6
1 2 3 4 5 6 7 8 910
Green LED:
.....
Flashing once every second: the device is energized.
Flashing once up to 5 times: to know which parameter
the bargraph is indicating
Push-button
Red led:
-
: device in Read mode
- : device in Parameterizing
mode
-
.....
ashing
1 up to 5times: error (see
chapter10.5)
Switches1 to 5: to set the device parameters
(frequency of the main supply, lter of the meas-
urements, measuring range)
Switch6: unused
10-LED bargraph:
To view and set the device parameters:
-
1 LED ON = 10% of the full scale (or
10seconds)
-
in Read mode
LED ashing "x" times = "x"% of the full scale (or
"x"seconds)
-
in Parameterizing mode
LED ashing once = 1% of the full scale (or
1second)
Fig.25: Electronic board of the device
