Technical data
6.6. Electrical data
Operating voltage • 18...36VDC,
• ltered and regulated
• oscillation rate: ±5%
• Connection to main supply: per-
manent (through external SELV and
through LPS power supply)
Specications of the
power source (not
supplied)
• Limited power source according to
IEC 62368-1, Appendix Q
• or limited energy circuit according
to IEC61010-1, Paragraph9.4
• SELV/PELV with UL-approved
overcurrent protection designed
according to IEC61010-1, Table 18
(e.g. Block PM-0124-020-0)
Current consumption
• 220mA (at 18VDC)
Current output
• Type of output • 4...20mA, sinking or sourcing
wiring
• Accuracy • ±1% (0.16mA)
• Refresh time • 100ms
• Max. loop impedance • 1100Ω at36 VDC,
330Ω at 18VDC
Frequency output
• Frequency • 0...240Hz
• Duty cycle • 50%±1%
• Max current • 100mA max.
• Protected against
short-circuits and
polarity reversal
• yes
Relay output To use the relay outputs in a wet
location, observe the following
DANGER safety instruction.
• Normally open or normally closed,
depending on the wiring
• max. 30VAC and 42Vpeak/ 2A
or 60VDC/ 1A max.
Alarme
• Full scale exceeded • 22mA and 256Hz
• Error signal • 22mA and 0Hz
DANGER
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶ If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of
max. 16Vrms and 22.6Vpeak.
- or energize the relay outputs with a direct voltage of
max.35VDC.
