Technical data
+10
+30
+50 +70
0
2
1
3
4
5
6
7
8
9
10
P [bar]
T [°C]
PVDF (PN10)/Metal
PVC + PP
PVC (PN10)
PP (PN10)
Fig.5:
Fluidpressure-temperaturedependencyofthe8041
withaowsensorholderinPVDF,insertedintoanS020
ttinginmetal,PVDF,PVCorPP
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
-20 0 +20 +40 +60 +80 +100 +120
PVDF (PN10)
PVC (PN10)
PP (PN10)
T (°C)
P (bar)
PVC + PP
PVDF
+150
DN100 for
measuring devices
with a clamp connection
(PN10)
Metal
(PN16)
1)
1)
Except DN100 for measuring devices with a clamp connection
Fig.6: Fluidpressure-temperaturedependencyofthe8041
withaowsensorholderinstainlesssteel,insertedinto
anS020ttinginmetal,PVDF,PVCorPP
english
Type 8041
