Burkert 8041 - Read and Parameterizing Mode Diagram

33
Adjustment and commissioning
9.3. General diagram of the Read and Parameterizing modes
X
1
2
Read mode Parameterizing mode
Flow zero calibration
Full scale calibration
alternately
Release when
desired function
is displayed*
Conrm the
choice displayed
Calibration in progress
Hold>2s
Hold>2s
* If no action for 10s, the device goes back to Read mode, using the parameters from the previous adjustment.
