Burkert 8041 - Page 34

34
Adjustment and commissioning
X
X
......
X
2
2
1
Relay
Short press
Short press
Short press
Short press
Current way of
switching*
Current low switching
threshold*
Current high
switching threshold*
Current time delay
before switching*
Hysteresis switching
Window switching
alternately
Release when
desired function is
displayed*
Conrm the choice displayed
Hold>2s
Unit increment: LED
ashes up to 9 times
The LEDs then come
on one after the other
(increment in factors
of ten)
Release with the
desired factor of
ten is reached*
Press and hold
to set the units
Unit increment:
LED ashes up to
9times
Release
with the
desired unit is
reached*
Conrm the dis-
played value
Hold>2s
Repeat the sequence if necessary
Hold>2s
Hold>2s
Hold>2s
Hold>2s
* If no action for 10s, the device goes back to Read mode, using the parameters from the previous adjustment.
english
Type 8041
