Technical data
Identification on the device Certification Variable key
UL-recognized PU01
Measuring
Equipment
EXXXXXX
®
UL-listed PU02
6.2.3 Material data of a 8025 Batch in panel version
Part Material
Housing /cover PC
Frontfoil / Screws Polyester / Stainless steel
Cable glands PA
Identification label Polyester
6.2.4 Dimensions of a 8025 Batch in panel version
→ Please refer to the technical data sheets regarding the dosing controller type 8025 Batch in panel version,
available at: www.burkert.com
6.2.5 Electrical data of a 8025 Batch in panel version
12...36 V DC power supply
• filtered and regulated
• SELV circuit (safety extra low voltage), with a safe
energy level
• oscillation rate: ±10%
Power source (not supplied)
for versions supplied with 12..36 V DC
• limited power source according to §9.4 of
EN 61010-1 standard
• or class 2 source according to UL 1310/1585 and
EN 60950-1 standards
Maximum current consumption version
12...36 V DC
70 mA
Pulse output (transistor) DO1 and DO4
polarized, potential-free
• type • NPN/PNP (wiring dependant)
• DO1 function • pulse output (can be configured and parametered)
• DO4 function • dosing state (can be configured and parametered)
• frequency (f) • 0,6...2200 Hz
• electrical data • 5...36 V DC, 100 mA max.,
voltage drop 2,7 V DC at 100 mA
• duty cycle
- if 0,6 < f < 300 Hz - > 0,45
- if 300 < f < 1500 Hz - > 0,4
- if 1500 < f < 2200 Hz - < 0,4
• protection • galvanically insulated, and protected against over-
voltages, polarity reversals and short-circuits
