Operating and functions
10.6.7 Doing a dosing in dosing mode "LOC. REP."
The dosing mode "LOC. REP." allows for starting, via the navigation keys, the dosing of the quantity determined
by a Teach-In procedure.
Danger
Danger due to electrical voltage.
▶ Disconnect the electrical power for all the conductors and isolate it before carrying out work on the system.
▶ Observe all applicable accident protection and safety regulations for electrical equipment.
→ Wire the output DO4 as described in Fig. 39.
→ Connect the valves to the DO2 and DO3 outputs: see chap. 8.14.
→ Start the device again.
→ Configure the device with this dosing mode: see chap. 10.7.13.
→ Do a dosing as shown in Fig. 55.
• If the generation of alarms (alarm "DURING") for problems occurring during a dosing has been activated
(see chap. 10.7.16), an alarm is generated if there is no flow rate measured in the pipe whereas the
valves are open. See chap. 11.3.4 to solve the problem.
• If the generation of alarms (alarm "AFTER") for problems occurring at the end of the dosing has been
activated (see chap. 10.7.17), an alarm is generated if there is still flow in the pipe whereas the valves
are closed. See chap. 11.3.4 to solve the problem.
English
Type 8025 - 8035 - SE35 BATCH
