Electrical installation and Wiring
8.9 Connecting the remote flow sensor to a 8025 Batch
in panel-mounted or in wall-mounted version
Only move the selectors when the power supply is off.
Before connecting the flow sensor to the dosing controller 8025 Batch, in panel-mounted or in wall-
mounted version:
• Set selector "SENSOR TYPE" depending on the output signal originating from the flow sensor. See
Fig. 33 and Tab. 3, page 54.
• If selector "SENSOR TYPE" is set on "NPN/PNP", set selector "SENSOR SUPPLY" depending on the
dosing controller supply voltage. See Fig. 34 and Tab. 3, page 54.
• Set selector "LOAD" depending on the type of signal sent out by the flow sensor and on the load
wanted on terminal 1 "PULSE INPUT" of terminal block "FLOW SENSOR". See Tab. 3, page 54.
Selector
C
makes it possible to configure the type of signal the device, receives from the remote flow sensor.
Set the selector on "NPN/PNP" (default position) when
the signal from the flow sensor which is connected to the
device is either:
• a pulse signal, NPN or PNP
• an "on/off" signal (Reed relay for example)
• a 0-5 V DC standard voltage signal (TTL, for example)
→ Set the selector on "COIL" when the
signal from the flow sensor which is
connected to the device is a sine-wave
signal (coil).
C
SENSOR
TYPE
COIL NPN/PNP
SENSOR
TYPE
COIL NPN/PNP
Fig. 33 : Using selector "SENSOR TYPE" on the 8025 Batch in panel or in wall-mounted version
When selector "SENSOR TYPE" above
is set on "NPN/PNP", selector
A
makes it possible to configure the supply
voltage for the remote flow sensor.
SENSOR
SUPPLY
+5V
L+
(L+)-12V
A
→ If the device is energized with a 115/230 V AC power supply, set
selector "SENSOR SUPPLY" on "L+" (default position).
→ If the device is energized with a 12...36 V DC power supply,
set the voltage selector "SENSOR SUPPLY" depending on the
voltage supply needed by the remote flow sensor: "+5V", "L+" or
"(L+)-12V" (default position).
Fig. 34 : Using selector "SENSOR SUPPLY" on the 8025 Batch in panel or in wall-mounted version
