Technical data
UL-Certification
Finished products with variable key PU01 or PU02 are UL-certified products and comply also with the following
standards:
• UL 61010-1
• CAN/CSA-C22.2 n°61010-1
Identification on the device Certification Variable key
UL-recognized PU01
Measuring
Equipment
EXXXXXX
®
UL-listed PU02
6.6.3 Fluid data of a SE35 Batch with a S070 or a S077
Type of fluid
Please refer to the Operating Instructions of the concerned sensor-fitting
S070 or S077
Fluid temperature
The fluid temperature may be restricted by the fluid pressure and the
material the S070 or S077 sensor-fitting used is made of
• Please refer to the Operating Instructions delivered with the sensor-fitting
S070 or S077 or to the concerned technical datasheets
Fluid pressure
The fluid pressure may be restricted by the fluid temperature and the
material the S070 or S077 sensor-fitting used is made of
• Please refer to the Operating Instructions delivered with the sensor-fitting
S070 or S077 or to the concerned technical datasheets
Flow rate measurement
• Measurement range
- viscosity > 5 mPa.s - S070 : 2...1200 I/min
- S077 : 2...1200 I/min
- viscosity < 5 mPa.s - S070 : 3...616 I/min
- S077 : 3...616 I/min
• Measurement deviation
- with standard K-factor of the
sensor-fitting
- S070 : ±0,5% of the measured value
1)
- S077 : ±1% of the measured value
1)
- with K-factor determined with
a teach-in procedure
- S070 : ±0,5% of the measured value
1)
(at the value of the teach-in
flow rate)
- S077 : ±0,5% of the measured value
1)
(at the value of the teach-in
flow rate)
• Repeatability • ±0,03% of the measured value
1)
1)
Determined in the following reference conditions: medium = water, water and ambient temperatures 20 °C, min. upstream
and downstream distances respected, appropriate pipe dimensions
