Electrical installation and Wiring
Warning
Risk of injury due to unintentional switch on of power supply or uncontrolled restarting of the
installation.
▶ Take appropriate measures to avoid unintentional activation of the installation.
▶ Guarantee a set or controlled restarting of the process subsequent to any intervention on the device.
• Use a filtered and regulated 12...36 V DC power supply. The circuit has to be safety extra low voltage
(SELV), with a safe energy level.
• Make sure the installation is equipotential. See chap. 8.3.
• Do not install the cables near high voltage or high frequency cables; if a combined installation cannot be
avoided, a minimum space of 30 cm should be respected.
• Protect the device power supply by means of a 300 mA fuse and a switch.
• Protect the power supply of each transistor output by means of a 125 mA fuse.
• Protect the relays by means of a max. 3 A fuse and a circuit breaker (depending on the process).
• Do not apply both a dangerous voltage and a safety extra-low voltage to the relays.
Insert the supplied stopper gaskets into the unused cable glands to ensure the tightness of the device.
8.2 Specifications of the connection cables
8.2.1 Dosing controller 8025 Batch in compact version, 8035
Batch and SE35 Batch
The electrical connection is done via terminal blocks and via two M20x1,5 cable glands.
Specifications of cables and conductors Recommended values
• Cable type • Shielded (not supplied)
• Cross section of wires • 0,2...1,5 mm
2
• Diameter of each cable if only one cable is used per
cable gland
• 6...12 mm
• Diameter of each cable if two cables are used per
cable gland
• 4 mm, with the supplied multi-way seal
• Length • max. 50 m
• Operating temperature • min. 80°C (min. 90°C for UL recognized version)
