Operating and functions
The activation duration of the digital input DI1 is counted even if the dosing has been interrupted.
→ To interrupt the dosing, press
ENTER
: the valve connected to output DO2 and possibly the valve connected
to output DO3 close, the device state LED flashes at a 1 Hz-frequency and the DO4 output (if configured to
transmit the device state, see chap. 10.7.26) generates a 1 Hz-frequency.
CONtiNUE
RESEt
→ To continue the dosing via the digital inputs:
• let the digital inputs DI2 and DI3 deactivated,
• then send a pulse on DI4.
→ To continue the dosing via the navigation keys, when the digital inputs DI2 and DI3 are
deactivated:
• display "CONTINUE" by pressing key
0......9
or ,
• then press key
ENTER
.
→ To abort the dosing via the digital inputs:
• activate one of the digital inputs DI2 or DI3,
• then send a pulse on DI4.
→ To abort the dosing via the navigation keys, when the inputs DI2 and DI3 are deactivated:
• display "RESET" by pressing key
0......9
or ,
• then press key
ENTER
.
113 L
The counting of the dosing quantity continues.
Process level: the device is ready for a new dosing.
Fig. 51 : Interrupting the dosing, in dosing mode "EXT. [T]"
English
Type 8025 - 8035 - SE35 BATCH
