BWT COVERDECK AX-IN - Coverdeck Ax-In Axle; Axle, Diameter 190 or 192 MM

PROTECTION & SAFETY
12 2020/11 - Version: B -
Code : 34561
COVERDECK AX-IN AXLE
1. Axle, diameter 190 or 192 mm
Product presentation
Ref
Description
Qty
1 Flange, motor side 1
2 Safety splint Ø3, A2 SS 2
3 Clamping pin Ø12 106mm, SS 1
4 Aluminium axle 1
5 HE nut M8 A4 SS 4
6
HSHC screw M8 x 35 A4 SS
4
7
Flange, bearing side
1
8 Stainless steel clevis mount 1
CAUTION
The curved side on the top of the flange should be oriented towards the axle.
