BWT COVERDECK AX-IN - Civil Engineering; With Masonry Pit Wall; With a Separating Pit Wall

PROTECTION & SAFETY
9 2020/11 - Version: B -
Code : 34561
3. Civil engineering
3.1. With masonry pit wall
Pool width ≤ 6.09 m Duckboarding 830 950
Beam
133 mm
Distance to wall
880
1000
Wall height 210
Distance to beam support
plate
900 1020
Coping M30
M40
M55
Distance to the cover flange 130 180
Water 135 125 110 Distance to duct 305 355
Standard separating pit wall width: Wall width = 250 mm
Minimum cover pit depth: pit depth = min 1.06 m
3.1. With a separating pit wall
Pool width ≤ 6,09 m Duckboarding 680 830 830 950
Beam 133 mm Corner 90° 90° R=150 R=150
Wall height 210
Dist to beam support
plate
750 900 900 1020
Coping M30 M40 M55 Dist to cover flange 130 180 275 330
Water 135 125 110
Standard separating pit panel width = 40 mm
Minimum cover pit depth: pit depth = min 1.06 m
Standard vertical radius: R = square corner or 150 mm
Distance to beam support plate
Distance to beam support plate
Distance to cover flange
Distance to cover flange
Cover pit depth
Cover pit depth
Partition th.
Pool width
Return fitting
Return fitting
Main drain
Pool width
Distance to wall
Wall th.
Wall height
Water
Dist to duct
Dist to duct
