28 2020/06 - Indice de révision : A -
2.2. Assembly of the cover apron, slats finished with silicon
Engage the tongue and groove of the two slat sections (the slats may be bent while you slide them together).
Slide them together carefully until the slats are aligned with each other.
Place a dot of PVC glue (not supplied) on the retainer before clipping it into the notch provided under the slat
apron.
2.3. Assembly of the complete cover
Place the first slat section (section with the slat equipped with axle/ slat apron connection straps) on the surface
of the water.
Line up the next slat section and slide it onto the first.
Push the assembled section aside on the water to proceed with assembly of the next section.
Repeat this procedure until you reach the last section equipped with the safety straps.
2.4. Attach the slat apron to the axle
Ø 190 or 192 mm axle:
Insert the black clip in the U located in the axle.
