42 2020/06 - Indice de révision : A -
3.1. Duckboarding angle iron
For renovation projects, the angle iron allows the duckboarding to be laid without pulling up the coping.
2 Aluminium angle iron 50 x 50 x 5 2 m
3 Wood screw TH Ø6 x 40 A4 SS 5
4 Washer Z6 A4 SS 5
A : concrete area for fastening.
Install the bushing 25 mm from the top of the pool wall.
