16 2020/11 - Version: B -
4. Disengaging the AX-IN motor
The motor can be disengaged to secure the pool in the event of a problem with the motor.
Undo the screws holding the casing in position. Remove the casing.
Detach the deck box cable and remove it, leaving a needle in the corrugated sheath.
Rotate both axles by 180°.
Pull gently on the slat apron to roll it out over the water. Be careful not to let the slat apron pick up speed as it
rolls out. The cable will wind around the Aluminium axle.
Secure the pool with safety fasteners.
