Specifications
SPECIFICATIONS
All hardware and software needed for operating the simulator are provided. In the event there is a
need to extend the instructor tablet to other manikins or computers, contact CAE Healthcare for
further instructions.
Size and Weight
Ambient Temperature Range
Maximum Altitude
Size Weight
Manikin/Simulator 69” H x 22” W x 15” D
(175 cm x 56 cm x 38 cm)
48.5 lbs (22 kg)
Instructor Tablet 9.34” H x 6.65” W x 0.24” D
(2.4 cm x 32.5 cm x 22.7 cm)
15.1 oz (429 g)
Operation Storage Relative Humidity
Manikin/Simulator 40°F to 104°F
(4°C to 4°C)
40°F to 122°F
(4°C to 50°C)
0% to 90%
non-condensing
Tablet 50°F to 95°F
(10°C to 35°C)
-13°F to 113°F
(-24°C to 45°C)
0% to 90%
non-condensing
For Operation For Storage For Shipping
Tablet 10,000 ft (3,048 m) 15,000 ft (4,572 m) 35,000 ft (10,668 m)
