APPENDIX B – VIPER SC+™ SPECIFICATIONS
These specifications are typical and subject to change without notice.
GENERAL SPECIFICATIONS
Model Number
Frequency Range
Channel Bandwidths Available
FCC/IC Certified Models
140-5018-502
136 - 174 MHz
6.25 kHz, 12.5 kHz, 25 kHz, 50 kHz
140-5028-504
215 - 246 MHz*
6.25 kHz, 12.5 kHz, 25 kHz, 50 kHz, 100 kHz
140-5048-302
406.1125 - 470.000 MHz
6.25 kHz, 12.5 kHz, 25 kHz, 50 kHz
140-5048-502
450.000 - 511.975 MHz
6.25 kHz, 12.5 kHz, 25 kHz, 50 kHz
140-5098-304
880 - 902 MHz
12.5 kHz, 25 kHz, 50 kHz, 100 kHz
140-5098-504
928 - 960 MHz
12.5 kHz, 25 kHz, 50 kHz, 100 kHz
ETSI/ACMA Certified Models
140-5018-600
142 - 174 MHz
12.5 kHz, 25 kHz (ETSI/AS/NZ)
140-5048-400
406.1125 - 470.000 MHz
12.5 kHz, 25 kHz (ETSI/AS/NZ)
140-5048-600
450.000 - 511.975 MHz
12.5 kHz, 25 kHz (ETSI/AS/NZ)
Frequency Stability
1.0 ppm for all models except the models specified below;
0.50 ppm for 140-5028-504, 140-5098-304, and 140-5098-504
Modes of Operation
Simplex, Half-Duplex
Frequency Increment
1.25 kHz
Power Source
10-30 V DC, Negative GND
The Viper is UL approved when powered with a listed Class 2 power supply.
RF Impedance
50 Ω
Specified Temperature
- 30° to + 60° C
Operating Temperature
- 40° to + 70° C
Storage Temperature
- 40° to +85°C, non-condensing RH
Operating Humidity
5% to 95% non-condensing RH
Rx Current Drain at 25°C
DC Input 10 V
DC Input 20 V
DC Input 30 V
690 mA (max.)
600 mA (typ.)
345 mA (max.)
300 mA (typ.)
260 mA (max.)
225 mA (typ.)
Tx Current Drain at 25°C
Power Out
DC Input 10 V
DC Input 20 V
DC Input 30 V
@ Max. Power
6.0 A (max.)
3.8 A (typ.)
60 W (max.)
2.7 A (max.)
2.0 A (typ.)
54 W (max.)
1.8 A (max.)
1.4 A (typ.)
54 W (max.)
@ 30 dBm (1 W)
1.8 A (max.)
1.4 A (typ.)
1.0 A (max.)
0.8 A (typ.)
0.8 A (max.)
0.6 A (typ.)
Cold start
35 seconds
Nominal Dimensions
5.50 in. W × 2.125 in. H × 4.25 in. D (13.97 cm × 5.40 cm × 10.8 cm) chassis only
Overall Dimensions
6.50 in. W × 2.17 in. H × 4.74 in. D (16.5 cm × 5.51 cm × 12.0 cm) with flat mount plate
Mounting Options
Mounting plate/pattern and DIN Rail
Shipping Weight
2.4 lbs. (1.1 kg)
