Viper SC+™ IP Router for Licensed Spectrum PN 001-5008-000 Rev. C | Page 68
Destination Port
The UDP/TCP destination port number. (A value of 0 means any value.)
DSCP
The Differentiated Services Code Point (DSCP) consists of the six (6) most significant bits of the eight-bit Type of
Service (ToS) field in the IP header. Select Any to not filter by this value. The following table contains DSCP values
and descriptions.
Table 14 DSCP (Differentiated Services Code Point) Values and Descriptions
Value
Description
0
CS0 – 000000 – Best Effort
8
CS1 – 001000 – Class 1
16
CS2 – 010000 – Class 2
24
CS3 – 011000 – Class 3
32
CS4 – 100000 – Class 4
40
CS5 – 101000 – Express
48
CS6 – 110000 – Reserved
10
AF11 – 001010 – Class 1 Low
12
AF12 – 001100 – Class 1 Medium
14
AF13 – 001110 – Class 1 High
18
AF21 – 010010 – Class 2 Low
20
AF22 – 010100 – Class 2 Medium
22
AF23 – 010110 – Class 2 High
26
AF31 – 011010 – Class 3 Low
28
AF32 – 011100 – Class 3 Medium
30
AF33 – 011110 – Class 3 High
34
AF41 – 100100 – Class 4 Low
36
AF42 – 100100 – Class 4 Medium
38
AF43 – 100110 – Class 4 High
46
EF – 101110 – Expedited Forwarding
Protocol
The protocol number in the IP header of the packet. Possible selections are All, ICMP, TCP, and UDP. Leave this
filed set to All if this value does not matter.
TCP ACK Only
When this option is checked, the filter will look for TCP packets with a TCP header only (no TCP data) and with only
the ACK flag set.
Transmit Queue
Specify the above transmit queue to use for packets that correspond to all of the criteria in the filter defined
above.
Add — Click to add filters.
Cancel — Click Cancel to cancel any changes to filters.
