Wireless Configuration
The wireless settings are divided into the following:
 Radio configuration
 WLAN configuration
Radio Configuration
cnPilot Enterprise AP is a dual band radio solution which operates on 5GHz and 2.4GHz bands
concurrently. The dashboard menu in the UI displays the channel and band from the CLI, show
wireless radios displays the details of the radio.
The following table lists the fields that are displayed in the Configure > Radio page and select
Radio 1(2.4GHz) or Radio 2(5GHz) from the drop-down list.
Table 5: Configure: Radio parameters
Parameter
Description
Default Value
Enable
Enables operation of this radio.
─
Channel
Primary operating channel.
Auto
Channel Width
Operating width of the channel.
20MHz for 2.4GHz and
80MHz for 5GHz
Transmit Power
Radio transmit power in dBm (1 to 30)
30dBm
Antenna Gain
Gain of connected antenna, in dBm (1 to 30)
─
Beacon interval
Beacon interval in ms (100 to 3400)
100
Multicast Data
Rate
Multicast in highest-basic, lowest-basic and highest-
supported.
Highest Basic for
2.4GHz and Lowest
Basic for 5GHz
The default channel configuration is set to auto, with this the AP sets the radio to best available
channel based on the interference and Noise Floor.
The country-code set in System page effects channel selection. Only the channels that are allowed
in the country code should be selected.
You can configure the above parameters through the UI or CLI.
In the UI
1. Navigate to the Configure > Radio tab and select Radio 1(2.4GHz) or Radio 2(5GHz) from the
drop-down list. The following fields are displayed in Radio:
a. Select the Enable checkbox to enable the operations of this radio.
b. Select the primary operating channel from the Channel drop-down list.
