Network Configuration
This section introduces the configuration of various network elements such as Ethernet ports,
SVIs, DHCP servers, DNS proxy, management VLAN access, NAT, and port forwarding. Depending
of the use case, the required elements can be configured.
Ethernet Ports
The following table describes the parameters displayed in the Network Configuration > Ethernet
Configuration page.
Table 12: Configure: Ethernet Ports parameters
Parameter
Description
Values
Mode
Configure Ethernet port in either trunk or access mode.
Trunk Mode: Allows traffic with different user defined
VLANs (refer allowed VLANs list) to egress & ingress.
One of these VLANs can be defined as native VLAN.
Traffic with native VLAN will map to untagged traffic
based on whether native VLAN is tagged or untagged.
Access Mode: Allows traffic with specific user defined
VLAN (called access VLAN) to egress as untagged and
allowed only untagged traffic to ingress and map to
access VLAN.
trunk/access
Default mode for
Eth1 and Eth2 is
access.
Access
VLAN*
Untagged traffic on access port will map to the access
VLAN inside the device.
1 - 4094
Allowed
VLANs^
List of all VLANs which are allowed to ingress and
egress from the trunk port and are separated by
commas.
E.g. 1,14,100,200-567
VLAN List
Native
VLAN^
Marks one of the VLANs from allowed VLAN list as
native VLAN.
1-4094
Native
Tagged^
Maps native VLAN traffic of device to untagged traffic
on Ethernet (when enabled) otherwise keep it tagged on
Ethernet side.
Enable/Disable
*: valid only in access mode
^: valid only in trunk mode
