Make sure all tools and materials necessary are within reach to install the edge in maximum safety, according to regulations in
force. The following figure illustrates the minimum equipment for the installer.
Before proceeding with the installation, it is necessary to:
• Make sure the area selected for the mounting of the base and for the unit itself presents no hazards;
• Provide for suitable omnipolar disconnection device with more than 3 mm between contacts to section power supply;
•
Connections inside the case made for protection circuit continuity are allowed as long as they include additional insulation with
respect to other internal drive parts;
• Install suitable tubes and ducts for electric cable passage to guarantee protection against mechanical damage;
Installation must be carried out by expert qualified personnel and in full observance of regulations in force.
5 Installation
4.4 Size measurements
Measurements in mm
5.1 Preliminary checks
5.2 Tools and materials
