0.4 01/2012 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
5.8 End stop adjustment
Similarly, open the bar and adjust the free damper, to regulate the horizontal position (= closing).
If any adjustment of the vertical position (= opening) is needed, open the inspection
door and rotate the free damper clockwise (to increase the bar’s run) or counter-
clockwise (to decrease the run).
N.B.: perform this procedure after fi nishing the electrical connections.
Close the door and power up the system, activate the barrier to make sure it is parallel with the closed and at about 89° when open.
Warning! For greater safety and better unit performance, the bar’s opening and closing operations should be carried out with
the inspection hatch closed!
