- Release the gearmotor and
manually turn the spring to
increase or decrease traction until
the bar rests at 45°.
- Tighten the blocking nut and refasten the gearmotor.
Note: make sure the spring functions properly:
- the spring is loose when the bar is in the vertical position (at rest)
- the spring is tight when the bar is in the horizontal position (tense).
- Perform any electrical connections to the control panel (see electrical
connections paragraph).

CAME GARD 8 SERIES Specifications

General

Model	GARD 8 SERIES
Type	Automatic Barrier
Motor voltage	24 V DC
Power	300 W
Operating temperature	-20°C to +55°C
Protection rating	IP54
Input Voltage	230 V AC
Output Voltage	24 V DC
Protection Degree	IP54
Power supply	230 V AC
Opening time	4 to 8 seconds
