Analog Range and Resolution:
Differential with Input
Reversal
Single-Ended and
Differential without Input
Reversal
Notch
Frequency
(f
N1
) (Hz)
Range
1
(mV)
RMS
(µV)
Bits
2
RMS
(µV)
Bits
2
15000
±5000
±1000
±200
20.0
4.0
1.6
19
19
18
30.0
5.5
1.8
18
18
17
50/60
3
±5000
±1000
±200
1.2
0.24
0.10
23
23
22
5.0
1.1
0.24
20
20
20
5
±5000
±1000
±200
0.60
0.12
0.05
24
24
23
4.9
1.0
0.22
20
20
20
1
Range overhead of ~5% on all ranges guarantees that full-scale values will not cause over range
2
Typical effective resolution (ER) in bits; computed from ratio of full-scale range to RMS resolution.
3
50/60 corresponds to rejection of 50 and 60 Hz ac power mains noise.
Accuracy (does not include sensor or measurement noise):
l 0 to 40 °C: ±(0.04% of measurement + offset)
l –40 to 70 °C: ±(0.06% of measurement + offset)
l –55 to 85 °C (XT): ±(0.08% of measurement + offset)
Voltage Measurement Accuracy Offsets:
Typical Offset (µV RMS)
Range (mV)
Differential
with Input Reversal
Single-Ended or Differential
without Input Reversal
±5000 ±10 ±40
±1000 ±5 ±12
±200 ±2 ±6
Measurement Settling Time: 20 µs to 600 ms; 500 µs default
