Air/Water Heat Exchanger Connections
Note: Use tubing clamps to secure all hoses.
Connect one end of each of the two silicone tubes to the Control Unit by sliding them onto each of
the (IN/OUT) fittings at the rear of the Control Unit. Then connect the opposite end of each tube to
the rear of the air/ water heat exchanger by plugging directly onto the fittings on the exchanger rear
panel.
Connect the tube from the IN fitting of the Control Unit to the COOLANT OUT connection on the
Air/Water Heat Exchanger. Connect the tube from the OUT fitting on the Control Unit to the
COOLANT IN connection on the Air/Water Heat Exchanger.
