TE-BBR Instruction and Operation Manual
Software Menu Options
Although the use of the software is largely intuitive, the descriptions in this section may provide
assistance during training and initial use of the BBR computer interface. Additionally, the BBRw
software includes Help files for convenient on-screen reference during operation of the program. To
access the Help files, click on Help from the BBRw Main Menu or click on the Help buttons available
in most BBRw dialog windows.
Main Menu
Table 4: Test Menu Options
Name
Description
Run a New Test
Initiates a new test by opening a new test file and prompting for user
input
Open a Saved Test
Activates the Open dialog, permitting user selection of the
appropriate file(s)
Close a Test Window*
Closes the file associated with the currently active window
Export Data*
Exports data from the currently active window to a file with the
format specified (.csv or .dat file format)
Batch Export Data
Allows the user to select data files for export in ASCII format. The
.csv files provide all recorded temperature/deflection/ force values
for the selected test(s).
Print*
Opens the Windows print dialog
Print Preview*
Provides a screen preview of the printed output
Print Setup
Activated the Windows Print Setup controls
…,2…,3…,4
Lists the most recently opened files. Double-click the file name to
open the file
Exit
Exits the BBR software program
*option available only when test file is open.
Table 5: View Menu Options
Name
Description
Toolbar
Displays or hides the BBRw toolbar.
