Chapter 2
2-1
2.1 Basic Construction
2.1.1 Basic Construction
0007-6133
The following shows the major components of the extension delivery kit:
F-2-1
[1] No. 2 delivery motor
[2] No. 3 delivery motor
[3] Duplex inlet sensor
[4] No. 3 delivery sensor
[5] Extension delivery kit controller PCB
[6] No. 3 delivery solenoid
[7] Duplex delivery solenoid
[8] No. 1 delivery solenoid
[9] No. 2 delivery sensor
[10] No. 2 delivery tray full sensor
[1]
[2]
[3]
[4]
[7]
[8]
[9]
[10]
[6]
[5]
