Canon DADF-B1 - Pcbs

CHAPTER 5 TOROUBLESHOOTING
5-14
COPYRIGHT © 1999 CANON INC. CANON DADF-B1 REV.0 APR. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
B. PCBs
Figure 5-302
Table 5-302
Reference Name
1 ADF control
2 Last original sensor (U504)
3 Original Set sensor (U503)
4 Pre-registration sensor (U502)
5 Reversal outlet sensor (U505)
6 Original set indicator
[4]
[3]
[6]
[2]
[1]
[5]
