Table 67 – Jogger Kit-A1 Specifications
Item Specifications
Required Equipment
Staple Finisher-AC1 or Booklet Finisher-AC1
Paper Size
Standard
11” x 17”, LGL, LTR, LTRR, EXEC
Shift-Sort
Feed Direction: 7 1/8” to 17” (182 mm to 431.8 mm)
Cross Feed Direction: 8.27” to 11.7” (210 mm to 297 mm)
No Sort
Feed Direction: 7 1/8” to 17” (182 mm to 431.8 mm)
Cross Feed Direction: 7 1/8 to 11.7” (210 mm to 297 mm)
Paper
Weight
Shift-Sort
14 lb bond to 110 lb cover (52 to 300 g/m
2
)
No Sort
14 lb bond to 140 lb index (52 to 256 g/m
2
)
Paper Type
Thin (52 to 63 g/m
2
), Plain (64 to 105 g/m
2
), Recycled,
Heavy (106 to 300 g/m
2
), Coated (85 to 300 g/m
2
)
Maximum Stacking
Capacity
90
Plain and Heavy Paper (LTR and EXEC): Approximately 16.7” (423
mm)
Shift Amount
91
Approximately 4/5” (20 mm)
Power Source
From the finisher
Dimensions (W x D x H)
22.7” x 6.7” x 6.1” (577 mm x 169 mm x 154 mm)
Weight
Approximately 6.7 lb (3.0 kg)
Table 68 – Booklet Trimmer-F1 Specifications
Item Specification
Paper Size
13" x 19.2", 12" x 18", 11" x 17", LGL, LTRR and Custom size up to 13.0"
x 19.2" (330.2 mm x 487.7 mm)
Maximum Number of
Sheets That Can be
Trimmed
Up to 50 sheets/200 pages (80 g/m
2
)
Up to 48 sheets (80 g/m
2
) + 2 sheets (300 g/m
2
)
• If the cover sheet is thinner than the other sheets in the booklet, the
cover sheet may be scratched. It is recommended to use a thicker
sheet for the cover sheet.
• The maximum number of sheets can change, depending on the
connected host machine.
Trimming Width
Fore edge : 2 to 28 mm (0.08" to 1.10") (Minimum length in the transport
direction after trimming: 119.7 mm or 4.713")
Waste Tray Capacity
Approximately 5,000 sheets (whose grain crosses at right angles to the
transport direction. curl removal) (width 20 mm [0.78"], A4, 80 g/m
2
)
(If trims are curled, the machine might detect the full error with the small
amount of trims.)
Conveyer Capacity
Up to 15 booklets (10 sheets of thick sheets without cover)
(When the delivery tray is stored, the conveyor full condition is not
detected, and the continuous operation is possible.)
Power Source
From the Finisher / 300W Max
Dimensions (H x W x D)
Approximately 41" x 82 1/2" x 30 3/4" (1,040 mm x 2,095 x 779)
(with the delivery tray extended)
Weight
Approximately 392 lb (178 kg)
90 For the details on the stacking capacity by paper type, size, and delivery mode, refer to the Staple Finisher-AC1 or Booklet
Finisher-AC1 specifications.
91 If the paper width is from 7 1/8” (210 mm) to 9.1” (232 mm), the alignment position is fixed, and the shift amount changes,
depending on the paper width.
