Canon imagePROGRAF iPF6300S

To Next Page

To Previous Page

3. Pull the Printhead Fixer Lever forward all the way to open it completely.

4. Pull up the Printhead Fixer Cover to open it completely.

5. Remove the Printhead and press the OK button.

Maintenance and Consumables

Printheads

Replacing the Printhead iPF6300S

986
