Canon imagePROGRAF iPF6300S User Manual

•
Object Frame Style
You can select the object frame style for printing.
The following settings are available for the object frame style.
Setting Details
None You can print with no frame style.
Solid Line You can print the solid line as the frame style.
Dotted Line You can print the dotted line as the frame style.
Dashed Line You can print the dashed line as the frame style.
Crop Marks You can print with the crop marks.
Page Options Dialog Box
This dialog box appears when you select Page Options from the File menu. This allows you to configure the roll paper
length, object layout order, and margins of Free Layout.
•
Roll Paper Length
Set the length of one page to print on roll paper.
The following settings are available for roll paper length.
Setting
Details
Auto Settings The one-page length to be printed on roll paper is automatically set so that the laid-
out objects are printed on one page.
Manual Settings You can input the length of one page to print on roll paper in numerical characters.
Windows Software > Free Layout >
iPF6300S Page Options Dialog Box
3
269

Canon imagePROGRAF iPF6300S Specifications

General

Print Technology	Inkjet
Print Resolution	2400 x 1200 dpi
Maximum Print Width	24 inches
Ink Type	Pigment-based
Media Handling	Roll and cut sheet
Operating System Compatibility	Windows, macOS
Print Width (Maximum)	24 inches
Media Thickness	0.07 - 0.8 mm
Roll Paper Size	Up to 24 inches
Memory (Maximum)	256 MB
Dimensions (W x D x H)	28.3 x 32.5 x 15.1 inches
Weight	96.3 lbs
Ink Droplet Size	4 picoliters
Connectivity	USB 2.0, Ethernet
Number of Nozzles	15, 360
Ink Cartridge Configuration	Individual cartridges
Acoustic Noise	Approx. 50 dB
Print Speed (Black & White)	Approx. 1.3 minutes per A1 print
Media Types	Plain paper, photo paper, canvas
Operating Systems	Windows, macOS
Number of Colors	8
Power Consumption (Standby)	5W
