Canon imagePROGRAF iPF6300S

To Next Page

To Previous Page

If paper is jammed deep in the Paper Feed Slot, remove the roll feed unit, and then clear the paper jam. (See

"Clearing Jammed Paper (Paper Feed Slot).") →P.1013

•

If the paper is jammed by the Ejection Guide

Remove the jammed paper from the Output Tray.

After removing the paper, make sure there are no other scraps of paper in the printer.

•

If paper is jammed in the back of the printer

Remove the jammed paper from the back of the printer.

After removing the paper, make sure there are no other scraps of paper in the printer.

Troubleshooting

Problems Regarding Paper

Clearing a Jammed Sheet, Fed Manually iPF6300S

1020
