4. Display the Main sheet.

5. Select High Accuracy 600ppi in Input Resolution to Plug-in.

6. Select Highest Gradation 16bit in Input Bit to Plug-in.

7. Select the highest quality possible in Print Mode.

8. If required, adjust the colors using color matching.

Note

• For more information about the color matching, see "Adjust the Colors by Color Matching."

→P.345

9. Click the Print button.

Printing of the Adobe RGB16bit image begins.

Windows Software

Print Plug-In for Photoshop/Digital Photo Professional

iPF6300S Print High-Quality Adobe RGB16bit Images

347
