Canon imagePROGRAF iPF6300S

To Next Page

To Previous Page

Note

• You can select only after Driver Matching Mode has been selected in Matching Mode.

•

Input Profile

Select the input profile.

Note

• You can select only after ICC Matching Mode has been selected in Matching Mode.

•

Printer Profile

Select the printer profile.

Note

• (Using Mac OS X 10.4)You can select only after ICC Matching Mode or ColorSync has been selected

in Matching Mode.

• (Using Mac OS X 10.5 or later)You can select only after ICC Matching Mode has been selected in

Matching Mode.

•

Soft Proof

When you place a checkmark here, ColorSync applies to the preview area.

Note

• You can select only after ColorSync has been selected in Matching Mode.

Mac OS X Software

Preview

iPF6300S Matching

537
