Canon imagePROGRAF iPF6300S

To Next Page

To Previous Page

Bring to Front

Moves the object to the frontmost position.

Send to Back

Moves the object to the backmost position.

Bring Forward

Moves the object one position to the front.

Mac OS X Software

Free Layout

iPF6300S Changing the Object Overlapping Order

581
