3. Search for the "Adobe Color Management Module (CMM)" item and select the Macintosh version.

4. Download the file by following the on-screen directions.

5. Start the installer in the downloaded file to perform the installation.

•

Adobe CMM System Requirements

The system requirements for Adobe CMM are as follows.

• Supported OS

Mac OS X 10.4.8 or later

• Supported CPU

PowerPC G4 or G5

Intel Core Duo, Intel Core 2 Duo, Intel Xeon processor

Note

• Check with Adobe for details.

•

How to Use Adobe CMM

The procedure for using Adobe CMM is as follows.

1. Display the Main sheet.

2. Select one of the ICC profiles as the Output Profile.

3. Click the ICC Conversion Options button.

Mac OS X Software

Print Plug-In for Photoshop/Digital Photo Professional

iPF6300S Using Adobe CMM

651
