Chapter 4
4-1
4.1 Service Parts
4.1.1 Service Parts
0012-6508
The service parts indicated below require careful handling.
1. Keep all packages with the warning not to turn over.
Pay careful attention to all individually packaged service part (carriage unit, purge unit, ink tank unit, and other parts) boxes marked "This side up" and handle
appropriately.
F-4-1
2. Feed roller
The feed roller is a functionally important part. Therefore, be careful that the roller is not scratched or marked during storage or transport of the service parts, when
removing them from the individual boxes, when assembling, or performing any other
operations.
