4.2 Disassembly/Reassembly
4.2.1 Disassembly/Reassembly
0014-8946
See the Parts Catalog for the disassembly and reassembly procedures. The following four main units do not apply.
Main Units:
1. Carriage unit
2. Ink tube unit
3. Purge unit
4. Ink tank unit
The parts layout illustration in the Parts Catalog shows the figure numbers associated with the disassembly procedure for each product.
Main unit disassembly and assembly flows
* Ink drainage in the dotted lines may be performed using either the automatic or manual ink drain procedure.
F-4-2
<Legend > c: Connector h: Hook s: Screw
Printer
Automatic ink drain
Manual ink drain
Left/right circle cover (L) (h1)
Left/right circle cover (S) (h1)
Left/right side covers (s3, h2)
Left/right tank cover units
(s3)
Upper rear cover (s5)
Upper cover
Open left/right ink tank units
(s4)
Upper left/upper right covers
(h1)
Rear cover right (s4)
Rear cover left (s2)
Left/right printheads
Left/right joint bases
Ink tube joint
Ink tube cover (s2)
Flexible cable (c3)
Carriage PCB cover (s4)
Carriage unit
Move the carriage to
above the platen
Head management sensor
(s1)
Lift unit (s5)
Cutter unit
Pulley base (s3)
1. Carriage Unit Disassembly Flow
