Canon imagePROGRAF iPF8400 Service Manual

Chapter 8
8-2
8.2 Warning Table
8.2.1 Warnings
0024-9330
*: Codes represent the numbers that are displayed in DISPLAY of the service mode and that are recorded in PRINT INF. As to PRINT INF, the codes record the
last 4 digits. Messages that are not accompanied by a code indication are not logged.
Display message Code* Condition detected Action
Cannot cut paper.
Lift the release lever and reload the
paper.
00000000-1011 Cannot cut perform force cutting because
paper is too short.
Reload new paper.
Paper Mismatch. 01061000-1021 Paper type mismatch Match the paper type in printer driver and the one
specified in printer panel.
Papr Size Mismatch 01063000-1022 Paper size mismatch Match the paper size in printer driver and the one
specified in printer panel.
MediaType Mismatch 01063000-1023 Paper size/type mismatch Match the paper type/size in printer driver and the ones
specified in printer panel.
PaperWidth Mismatch 01063000-1054 Roll media width mismatch
The occurrence conditions of roll paper
width mismatch have been met with
"Warning" set in [Detect Mismatch] in the
menu settings.
The warning is cleared when the print job is completed
or cancelled.
Mail box nearly full.
Delete unwanted data
011A1001-2901 The free hard disk space left for Personal
Boxes in the printer's hard disk does not
have more than 1 GB, combined.
Delete unneeded jobs stored in Personal Boxes.
Maximum jobs stored.
Delete unwanted data.
011A1006-2907 Saved jobs exceed the Personal Box
capacity.
Press the stop button to cancel the print job.
Delete print jobs from the queue.
Delete unneeded jobs stored on the hard disk.
The paper is too small. 013200D2-1051 Size clip error Check the media size check.
Change the media size.
GL2:W0501
The memory is full.
01340501-1040 Memory full (HP-GL/2) Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GL2:W0502
The parameter is out of
range.
01340502-1041 Invalid parameter (HP-GL/2) Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GL2:W0504
This command is not
supported.
01340504-1043 Invalid command (HP-GL/2) Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GL2:W0903
The memory is full.
01340903-1047 Overflow of replot buffer (HP-GL/2) Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GL2:W0904
The memory is full.
01340904-1048 Overflow of Polygon buffer (HP-GL/2) Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1221 01341221-1030 GARO (image mode) : Unknown
command
Verify the transmitted data before reprinting.
GARO W1222 01341222-1031 GARO (image mode) : Invalid parameter
count (no parameters)
Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1223 01341223-1032 GARO (image mode) : Required parameter
missing
Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1224 01341224-1033 GARO error Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1225 01341225-1034 GARO (image mode) : Other warning Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1226 01341226-103A GARO (image mode) : Image processing
table error
Verify that there is no image missing in print result.
Verify the transmitted data before reprinting.
GARO W1231 01341231-1035 GARO (setup) : Unknown command Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1232 01341232-1036 GARO (setup) : Invalid parameter count Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1233 01341233-1037 GARO (setup) : Required parameter
missing
Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1234 01341234-1038 GARO (setup) : Data out of bounds Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
GARO W1235 01341235-1039 GARO (setup) : Other warning Check if there is the non-image area of the print.
Verify the transmitted data before reprinting.
Problem with Printhead.
Chk printing results
01800500-1010 Number of non-discharging nozzles in
printhead:
Warning level
Clean the printhead.
Renew the printhead.
Identify the head management sensor unit.
Problem with Printhead R
Chk printing results
01800500-1012 Non-discharge occurred in printhead1 Clean the printhead.
Renew the right printhead.
Problem with Printhead L
Chk printing results
01800500-1013 Non-discharge occurred in printhead2 Clean the printhead.
Renew the left printhead.
Ink Level: Check 01810101-1001 Y ink tank near-empty Renew the ink tank.
No ink tank loaded.
Check ink tank.
01810101-1411 Y ink tank removal Install the Y ink tank.
